Components:

Heavy Duty Shelves Tubular welded box beam front and rear for maximum strength Exclusive triple bend side flanges for added strength Lapped and welded corners Top of shelf is punched to accept shelf dividers Uses four one piece shelf clips per shelf Can be installed together with both

Angle Back and T-Posts Roll formed into a unique shape for maximum strength The long leg is punched on 1-1/2" centers to allow independent shelf adjustment Angle Posts can be used in place of Beaded Front Posts if desired

Beaded Front Posts Beaded for strength Flush to permit straight-in/straight-out shelf installation, shelf changing and shelf loading. No tilting needed Get the full use of shelf area Punched on 1-1/2" centers to allow positioning of one shelf independent of other shelves

H-Posts Designed for high-density applications More than twice the capacity of standard posts Used at front and back Used with standard Hi-Tech components

One Piece Shelf Clip Each shelf requires four of these sturdy and compact clips Clips key firmly into post slots to hold shelves securely in place Fits Beaded Front, Angle Back Posts and T-Posts Provides independent shelf positioning on 1-1/2" centers Non-intrusive clip sits flush with inside edge of front posts

Hi-Tech™
Industrial Grade Steel Shelving

Continuing a tradition of quality established generations ago.

Hi-Tech Shelving is a complete shelving line with the strength needed to handle most industrial applications with the versatility needed for today's modern facilities. Every shelving unit is designed and engineered to handle daily use for a lifetime without losing its integrity.

A full compliment of accessories including full dividers, partial dividers, label holders, swinging doors, post splices for multilevel systems and foot plates are available to complete your steel shelf system.

QUICKSHIP: 5 day shipping on all in stock shelving!

Tons of options allow you to customize the metal shelves to your specific industry needs. Choose an open style unit for more accessibilty and visibilty, or choose the closed style for more security and containment. If high weight-capacity or multiple levels are needed, then you may want to select the high capacity H-posts for extra strength.

All Hi-Tech shelving comes in starter and/or adder units to allow for customization to any specification. In addition to free-standing, the Hi-Tech steel shelving units can be bolted side by side or back to back to create the best storage solution for your garage, warehouse, storage unit, stock room or other space.

Each Hi-Tech metal heavy-duty shelf has a tubular welded box beam in front and rear for maximum strength, exclusive triple bend side flanges for even more strength, lapped and welded corners, and the shelves are punched to accept shelf dividers. Each shelf is installed using only 4 shelf clips and can be installed together with both beaded front and angle back posts as well as T-posts and H-posts. Hi-Tech Steel Shelving is perfect for most medium-duty and heavy-duty product, tool and gear storage.

Hi-Tech shelving systems have been specially designed to allow for fast and easy assembly.

Open Starter units include:
two beaded front posts, two angle back posts, one pair of back sway braces, two pair of side sway braces and shelves with shelf clips applicable to unit ordered.

Open Adder units include:
one beaded front post, two angle back posts, one pair of back sway braces, one pair of side sway braces and shelves with shelf clips applicable to unit ordered.

Closed Starter units include:
two beaded front posts, two angle back posts, one set of back panels, two sets of side panels and shelves with shelf clips applicable to unit ordered.

Closed Adder units include:
one beaded front post, two angle back posts, one set of back panels, one set of side panels and shelves with shelf clips applicable to unit ordered.

• Open Shelving Catalog

• Closed Shelving Catalog

• Specifications

• Also Available from the Hi-Tech system:

  • Hi-Tech Medsafe Antimicrobial Shelving




GREENGUARD Certificates:

Indoor Air Quality Certificate

Children & Schools Certificate
